0.02% Precision Stationary Reference Standard

0.02% Precision Stationary Reference Standard

Nama merek:	GENY
Nomor Model:	SZ-03A-K6
MOQ:	1 buah
harga:	Bisa dinegosiasikan
Ketentuan Pembayaran:	L/C,T/T,D/P
Kemampuan Penyediaan:	100/Tahun

Informasi detil

Deskripsi Produk

Informasi detil

Tempat asal:

Sertifikasi:

ISO, CE

Nomor Model.:

SZ-03A-K8

Kelas akurasi:

0,02%

Voltase:

5V hingga 480V

Saat ini:

10mA hingga 120A

Kemasan rincian:

Kasing aluminium dengan karton

Menyediakan kemampuan:

100/Tahun

Menyoroti:

0.02% precision stationary standard

high accuracy reference standard

stationary standard with warranty

Deskripsi Produk

0.02% Precision Stationary Reference Standard

The SZ-03A-K8 series three phase standard meter incorporates advanced technologies including high-speed DSP, CPLD, MCU, and ADC with self-calibration capabilities. This sophisticated design enables high-speed AC signal sampling and specialized digital processing, resulting in a simplified structure while achieving exceptional 0.02% relative error measurement accuracy.

Key Features

High Precision Measurement

±0.02% measurement error for three-phase voltage, current, power, and electrical energy

Wide Measurement Range

Voltage: 5V to 480V | Current: 10mA to 120A

Multi-Parameter Testing

Synchronous measurement of three-phase voltage, current, power, electrical energy, power factor, phase, and frequency

Comprehensive Measurement Modes

Supports multiple configurations including three-phase four-wire (3P4W), three-phase three-wire (3P3W), single-phase two-wire (1P2W), single-phase three-wire (1P3W), and two-phase three-wire (2P3W) for both active and reactive power measurements

Harmonic Analysis

Measures waveform distortion factor and 2nd to 21st harmonic content with bar chart display

Test Bench Verification

Analyzes voltage, current, and phase asymmetry rates along with power stability assessment

Waveform Display

Synchronous display of voltage and current waveforms

Advanced Standard Meter Functions

Configurable energy pulse constant (automatic or manual), error and standard deviation calculation, electricity quantity accumulation, and manual/external synchronous pulse power control

Software Calibration

Full-range and phase angle calibration via software for enhanced reliability and efficiency

Communication Capabilities

Dual communication ports (RS-232 and RS-485) for PC connectivity and test bench integration, enabling automated measurement and calibration processes
